Victron Energy BlueSolar MPPT 250/100-Tr VE.Can
Victron Energy BlueSolar MPPT 250/100-Tr VE.Can
SKU: SCC125110441
Weight: 12.0 lb
Couldn't load pickup availability
- description
Victron Energy BlueSolar MPPT 250/100-Tr VE.Can Charge Controller
Ultrafast Maximum Power Point Tracking (MPPT)
Especially in case of a clouded sky, when light intensity is changing continuously, an ultra-fast MPPT controller will improve energy harvest by up to 30% compared to PWM charge controllers and by up to 10% compared to slower MPPT controllers.
Advanced Maximum Power Point Detection in case of partial shading conditions
If partial shading occurs, two or more maximum power points may be present on the power-voltage curve. Conventional MPPTs tend to lock to a local MPP, which may not be the optimum MPP. The innovative BlueSolar algorithm will always maximize energy harvest by locking to the optimum MPP.
Outstanding conversion efficiency
No cooling fan. Maximum efficiency exceeds 98%. Full output current up to 40°C (104°F).
Flexible charge algorithm
Fully programmable charge algorithm (see the software page on our website), and eight preprogrammed algorithms, selectable with a rotary switch (see manual for details).
Extensive electronic protection
Over-temperature protection and power derating when temperature is high. PV short circuit and PV reverse polarity protection. PV reverse current protection.
Internal temperature sensor
Compensates absorption and float charge voltage for temperature.
| Specification | MPPT 150/45 |
|---|---|
| Battery Voltage | 12 / 24 / 48V Auto Select (software tool needed to select 36V) |
| Rated Charge Current | 100A |
| Nominal PV Power | 12V 1a,b): 1450W 24V 1a,b): 2900W 36V 1a,b): 4350W 48V 1a,b): 5800W |
| Maximum PV Short Circuit Current 2) | 70A |
| Maximum PV Open Circuit Voltage | 150V absolute maximum (coldest conditions) 145V start-up and operating maximum |
| Maximum Efficiency | 99% |
| Self-Consumption | Less than 35mA @ 12V / 20mA @ 48V |
| Charge Voltage (Absorption) | Default setting: 14,4 / 28,8 / 43,2 / 57,6V (adjustable with: rotary switch, display, VE.Direct or Bluetooth) |
| Charge Voltage (Float) | Default setting: 13,8 / 27,6 / 41,4 / 55,2V (adjustable: rotary switch, display, VE.Direct or Bluetooth) |
| Charge Algorithm | Multi-stage adaptive (eight pre-programmed algorithms) or user defined algorithm |
| Temperature Compensation | -16 mV / -32 mV / -64 mV / °C |
| Protection | PV reverse polarity / output short circuit / over-temperature |
| Operating Temperature | -30 to +60°C (full rated output up to 40°C) |
| Humidity | 95%, non-condensing |
| Maximum altitude | 5000m (full rated output up to 2000m) |
| Environmental condition | Indoor, unconditioned |
| Pollution degree | PD3 |
| Data Communication Port | VE.Direct and VE.Can |
| Remote on/off | Yes (2 pole connector) |
| Programmable relay | DPST AC rating: 240VAC / 4A DC rating: 4A up to 35VDC, 1A up to 60VDC |
| Parallel operation | Yes, parallel synchronised operation with VE.Can (max. 25 units) |
| Enclosure | |
| Colour | Blue (RAL 5012) |
| PV Terminals | 35 mm² / AWG2 |
| Battery terminals | 35mm² / AWG2 |
| Protection Category | IP43 (electronic components), IP22 (connection area) |
| Weight | 4.5 kg |
| Dimensions (H × W × D) | 216 x 295 x 103 mm |
| Standards | |
| Safety | EN/IEC 62109-1, UL 1741, CSA C22.2 |
| 1a) If more PV power is connected, the controller will limit input power. 1b) The PV voltage must exceed Vbat + 5V for the controller to start. Thereafter the minimum PV voltage is Vbat + 1V. 2) A PV array with a higher short circuit current may damage the controller. |
|
